地球科学进展  2017, Vol. 32 Issue (10): 1062-1071    DOI: 10.11867/j.issn.1001-8166.2017.10.1062
综述与评述
石英ESR法物源示踪:认识与进展
魏传义1, 2, 刘春茹1, *, 李长安2, 3, 尹功明1, 李文朋1, 赵举兴2, 张增杰2, 张岱2, 孙习林2, 4, 李亚伟2
1. 中国地震局地质研究所,地震动力学国家重点实验室,北京 100029;
2.中国地质大学(武汉),地球科学学院,湖北 武汉 430074;
3.生物地质与环境地质国家重点实验室,湖北 武汉 430074;
4. Cluster Geology and Geochemistry, VU University Amsterdam, De Boelelaan 1085, 1081 HV Amsterdam, The Netherlands
Research Advances in ESR Provenance Tracing Methods of Quartz in Sediments
Wei Chuanyi1, 2, Liu Chunru1, *, Li Chang’an2, 3, Yin Gongming1, Li Wenpeng1, Zhao Juxing2, Zhang Zengjie2, Zhang Dai2, Sun Xilin2, 4, Li Yawei2
1.State Key Laboratory of Earthquake Dynamics, Institute of Geology, China Earthquake Administration, Beijing 100029, China;
2.School of Earth Sciences, China University of Geosciences, Wuhan 430074, China;
3.State Key Laboratory of Biogeology and Environmental Geology, Wuhan 430074, China;
4.Cluster Geology and Geochemistry, VU University Amsterdam, De Boelelaan 1085, 1081 HV Amsterdam, The Netherlands
 全文: PDF(4357 KB)   HTML
摘要:

石英ESR法物源示踪是一种新发展的沉积物源示踪方法。目前,用于沉积物源示踪研究的石英ESR信号心主要有热处理E??心,自然E??心、Al心和Ti心。从研究实例来看,热处理E??心、是物源示踪研究运用最广泛和最成熟的;自然E??心具有很好的应用前景;Al心和Ti心的物源示踪指示意义还处于实验观察和理论探索阶段。从研究对象来看,该方法已成功应用于东亚粉尘主要源区、黄土高原物源时空变化特征、日本群岛风成沉积物源时空变化特征及日本海沉积物源示踪的研究当中。此外,石英ESR法物源示踪在定量或半定量分析河流沉积物源示踪中也表现出了较好的应用前景。随着石英ESR测年技术的不断提高,该方法将在恢复区域性构造运动、地貌演化以及重建区域性的气候演化历史等方面具有独特的优势。

关键词: 物源示踪电子自旋共振(ESR)风成沉积物石英河流沉积物
Abstract:

The ESR (Electron Spin Resonance) signals of quartz is a newly developed sediment provenance tracing method. In this paper, the various ESR signals in quartz, historical development of quartz ESR signals in sediment provenance tracing, thermal stability characteristics of heat treated E’ center, the potential use of quartz nature E’ center and the irradiated Al/Ti center, as well as successful applications in aeolian sediments, river sediments and marine sediments provenance tracing, were briefly reviewed.
The most useful ESR centers of quartz include the heat treated E’ center, the nature E’ center, the Al center and the Ti center. According to recent application researches, the heat-treated E’ center is the most commonly practiced among them while the significance of provenance tracing by Al and Ti centers are still in experimental and theoretical stage. Moreover, nature signal intensities of quartz E’ center not only show a significant dependence on lithology both in bedrocks and deposits, but also can reflect the mixture ratio of deposits with different types of sourced bedrocks.
As for the study objects, this method has been successfully used in the studies of provenance area of East Asian dust, the temporal and spatial changes of Loess Plateau provenance, the provenance change of aeolian sediment over time and space on Japanese Islands, as well as sediment provenance tracing of Japan Sea sediments. In addition, the ESR provenance tracing of quartz has promising application prospect in quantitative and semi-quantitative analysis of fluvial sediment provenance tracing. Along with the development of ESR dating, this method can significantly reflect and reconstruct the relationship among regional tectonic movements, geomorphic evolution, and climate evolution.
In future work, the combination of trace elements provenance tracing and ESR signals provenance tracing in quartz will help improve and promote the development of sediments provenance tracing methods.

Key words: Quartz    Electron Spin Resonance    Asian dust    Provenance tracing.    Fluvial sediments
收稿日期: 2017-04-06 出版日期: 2017-10-20
ZTFLH:  P512.2
基金资助:

中国地震局地质研究所地震动力学国家重点实验室2016年度自主课题“石英ESR法物源示踪在河流沉积物源示踪中的探讨及应用”(编号:LED2016A08); 国家自然科学基金项目“江汉盆地宜昌冲积扇物源解析与区域地貌演化”(编号:41671011)资助.

通讯作者: 刘春茹 (1980-),女,吉林通化人,研究员,主要从事新构造年代学研究.E-mail:liuchunru0821@126.com
作者简介: 魏传义(1990-),男,山东淄博人,博士研究生,主要从事ESR法物源示踪和河流形成与演化研究.E-mail:weichuanyi@126.com
服务
把本文推荐给朋友
加入引用管理器
E-mail Alert
RSS
作者相关文章

引用本文:

魏传义, 刘春茹, 李长安, 尹功明, 李文朋, 赵举兴, 张增杰, 张岱, 孙习林, 李亚伟. 石英ESR法物源示踪:认识与进展[J]. 地球科学进展, 2017, 32(10): 1062-1071.

Wei Chuanyi, Liu Chunru, Li Chang&#x, an, Yin Gongming, Li Wenpeng, Zhao Juxing, Zhang Zengjie, Zhang Dai, Sun Xilin, Li Yawei. Research Advances in ESR Provenance Tracing Methods of Quartz in Sediments. Advances in Earth Science, 2017, 32(10): 1062-1071.

链接本文:

http://www.adearth.ac.cn/CN/10.11867/j.issn.1001-8166.2017.10.1062        http://www.adearth.ac.cn/CN/Y2017/V32/I10/1062

[1] Basu A, Young S W, Suttner L J, et al . Re-evaluation of the use of undulatory extinction and polycrystallinity in detrital Quartz for provenance interpretation[J]. Journal of Sedimentary Research , 1975, 45(4):873-882.
[2] Jackson M L. Oxygenisotopic ratios in Quartz as an indicator of provenance of dust[J]. Geological Society of America Special Papers , 1981, 186: 27-36.
[3] Suczek C A, Ingersoll R V. Petrology and provenance of Cenozoic sand from the indus cone and the Arabian Basin, DSDP sites 221, 222, and 224[J]. Journal of Sedimentary Research , 1985, 55(3):340-346.
[4] Wronkiewicz D J, Condie K C. Geochemistry of archean shales from the witwatersrand supergroup, south Africa: Source-area weathering and provenance[J]. Geochimica et Cosmochimica Acta , 1987, 51(9): 2 401-2 416.
[5] Vennemann T W, Kesler S E, O’Neil J R. Stable isotope compositions of Quartz pebbles and their fluid inclusions as tracers of sediment provenance: Implications for gold-and uranium-bearing Quartz pebble conglomerates[J]. Geology , 1992, 20(9): 837-840.
[6] McLennan S M, Hemming S, McDaniel D K, et al . Geochemical approaches to sedimentation, provenance, and tectonics[J]. Geological Society of America Special Papers , 1993, 284: 21-40.
[7] Smith M A, Pell S. Oxygen-isotope ratios in Quartz as indicators of the provenance of archaeological ochres[J]. Journal of Archaeological Science , 1997, 24(9): 773-778.
[8] Cullers R L. The geochemistry of shales, siltstones and sandstones of pennsylvanian-Permian age, Colorado, USA: Implications for provenance and metamorphic studies[J]. Lithos , 2000, 51(3): 181-203.
[9] Middleton F A, Strick P L. Basal-ganglia ‘projections’ to the prefrontal cortex of the primate[J]. Cerebral Cortex , 2002, 12(9): 926-935.
[10] Aléon J, Chaussidon M, Marty B, et al . Oxygen isotopes in single micrometer-sized Quartz grains: Tracing the source of Saharan dust over long-distance atmospheric transport[J]. Geochimica et Cosmochimica Acta , 2002, 66(19): 3 351-3 365.
[11] Bernet M, Bassett K. Provenanceanalysis by single-quartz-grain SEM-CL/optical microscopy[J]. Journal of Sedimentary Research , 2005, 75(3): 492-500.
[12] Ackerson M R, Tailby N D, Watson E B. Traceelements in quartz shed light on sediment provenance[J]. Geochemistry , Geophysics , Geosystems , 2015, 16(6): 1 894-1 904.
[13] Toyoda S, Goff F. Quartz inpost-caldera rhyolites of valles caldera, New Mexico: ESR finger printing and discussion of ESR ages[J]. Jemez Mountains Region : New Mexico Geological Society , Guidebook , 1996, 47: 303-309.
[14] Ono Y, Naruse T, Ikeya M, et al . Origin and derived courses of eolian dust quartz deposited during marine isotope stage 2 in East Asia, suggested by ESR signal intensity[J]. Global and Planetary Change , 1998, 18(3): 129-135.
[15] Attanasio D, Armiento G, Brilli M, et al . Multi-method marble provenance determinations: The carrara marbles as a case study for the combined use of isotopic, electron spin resonance and petrographic data[J]. Archaeometry , 2000, 42(2): 257-272.
[16] Duttine M, Villeneuve G, Bechtel F, et al . Electron paramagnetic resonance characterization of natural Quartz from different sources[J]. Comptes Rendus Geoscience , 2002, 334(13): 949-955.
[17] Toyoda S, Naruse T. Eoliandust from the Asian deserts to the Japanese islands since the last glacial maximum: The basis for the ESR method[J]. Transactions , Japanese Geomorphological Union , 2002, 23: 811-820.
[18] Crook N P, Hoon S R, Taylor K G, et al . Electron spin resonance as a high sensitivity technique for environmental magnetism: Determination of contamination in carbonate sediments[J]. Geophysical Journal International , 2002, 149(2): 328-337.
[19] Nagashima K, Tada R, Tani A, et al . Contribution of aeolian dust in Japan Sea sediments estimated from ESR signal intensity and crystallinity of quartz[J]. Geochemistry , Geophysics , Geosystems , 2007, 8(2),doi:10.1029/2006GC001364.
[20] Nagashima K, Tada R, Tani A, et al . Millennial-scale oscillations of the westerly Jet Path during the last glacial period[J]. Journal of Asian Earth Sciences , 2011, 40(6): 1 214-1 220.
[21] Sun Youbin, Tada R, Chen Jun, et al . Distinguishing the sources of Asian dust based on electron spin resonance signal intensity and crystallinity of Quartz[J]. Atmospheric Environment , 2007, 41(38): 8 537-8 548.
[22] Sun Youbin, Tada R, Chen Jun, et al . Tracing the provenance of fine-grained dust deposited on the central Chinese Loess Plateau[J]. Geophysical Research Letters , 2008, 35(1), doi:10.1029/2007GL031672.
[23] Sun Youbin, Chen Hongyun, Tada R, et al . ESR signal intensity and crystallinity of Quartz from gobi and sandy deserts in East Asia and implication for tracing Asian dust provenance[J]. Geochemistry , Geophysics , Geosystems , 2013, 14(8): 2 615-2 627.
[24] Toyoda S. The E ’ center in natural quartz: Its formation and applications to dating and provenance researches[J]. Geochronometria , 2011, 38(3): 242-248.
[25] Yamamoto Y, Toyoda S, Nagasima K, et al . Investigation of the temporal change of the sources of Aeolian dust delivered to East Asia using electron spin resonance signals in Quartz[J]. Geochronometria , 2013, 40(4): 355-359.
[26] Shimada A, Takada M, Toyoda S. Characteristics of ESR signals and tlcls of Quartz included in various source rocks and sediments in Japan: A clue to sediment provenance[J]. Geochronometria , 2013, 40(4): 334-340.
[27] Tissoux H, Voinchet P, Lacquement F, et al . ESR as a method for the characterization of alluvial sediments[J]. Radiation Measurements , 2015, 81: 2-8.
[28] Shimada A, Takada M, Toyoda S. Electron spin resonance signals of quartz in present-day river bed sediments and possible source rocks in the Kizu River Basin, Western Japan[J]. Geochronometria , 2016, 43(1): 155-161.
[29] Toyoda S, Nagashima K, Yamamoto Y. ESR signals in Quartz: Applications to provenance research—A review[J]. Quaternary International , 2016, 397: 258-266.
[30] Zeller E J, Levy P W, Mattern P L. Geologic Dating by Electron Spin Resonance. Radioactive Dating and Methods of Low-Level Counting[C].Vienna: International Atomic Energy Agency, 1967: 531-540.
[31] Odom A L, Rink W J. Natural accumulation of schottky-frenkel defects: Implications for a Quartz geochronometer[J]. Geology , 1989, 17(1): 55-58.
[32] Liu Chunru, Yin Gongming, Gao Lu, et al . Research advances in ESR geochronology of quaternary deposits[J]. Seismology and Geology , 2011, 33(2): 490-498.
[刘春茹, 尹功明, 高璐, 等. 第四纪沉积物 ESR 年代学研究进展[J]. 地震地质, 2011, 33(2): 490-498.]
[33] Liu Chunru, Yin Gongming, Rainer G. Research progress of the resetting features of Quartz ESR signal[J]. Advances in Earth Science , 2013, 28(1): 24-30.
[刘春茹, 尹功明, Rainer G. 石英 ESR 测年信号衰退特征研究进展[J]. 地球科学进展, 2013, 28(1): 24-30.]
[34] Liu Chunru, Yin Gongming, Han Fei, et al . ESR dating methodology and its application in dating quaternary terrestrial sediments[J]. Quaternary Sciences , 2016, 36(5): 1 236-1 245.
[刘春茹, 尹功明, 韩非, 等. 石英 ESR 测年法在第四纪陆相沉积物测年中的应用[J]. 第四纪研究, 2016, 36(5): 1 236-1 245.]
[35] Toyoda S, Voinchet P, Falguères C, et al . Bleaching of ESR signals by the sunlight: A laboratory experiment for establishing the ESR dating of sediments[J]. Applied Radiation and Isotopes , 2000, 52(5): 1 357-1 362.
[36] Tissoux H, Toyoda S, Falguères C, et al . ESR dating of sedimentary Quartz from two pleistocene deposits using Al and Ti-centers[J]. Geochronometria , 2008, 30(1): 23-31.
[37] Diao Shaobo. The Study and Application on Dating of Oxygen Vacancies in Quartz from Sediments[D]. Jilin: Jilin University, 2003.
[刁少波. 沉积物中石英氧空位测年及其应用[D]. 吉林:吉林大学, 2003.]
[38] Griscom D L, Friebele E J. Fundamental defect centers in Glass: 29 Si hyperfine structure of the nonbridging oxygen hole center and the peroxy radical in a SiO 2 [J]. Physical Review B , 1981, 24(8): 4 896.
[39] Griscom D L. Defect structure of glasses: Some outstanding questions in regard to vitreous silica[J]. Journal of Non-Crystalline Solids , 1985, 73(1): 51-77.
[40] Rink W J. Natural alpha recoil particle radiation and ionizing radiation sensitivities in Quartz detected with EPR: Implications for Geochronometry[J]. International Journal of Radiation Applications and Instrumentation. Part D. Nuclear Tracks and Radiation Measurements , 1991, 18(1): 163-173.
[41] Toyoda S, Ikeya M. Thermal stabilities of paramagnetic defect and impurity centers in Quartz: Basis for ESR dating of thermal history[J]. Geochemical Journal , 1991, 25(6): 437-445.
[42] Jani M G, Bossoli R B, Halliburton L E. Further characterization of the E ?? center in crystalline SiO 2 [J]. Physical Review B , 1983, 27(4): 2 285-2 293.
[43] Toyoda S, Hattori W. Formation and decay of the E ?? center and of its precursor[J]. Applied Radiation and Isotopes , 2000, 52(5): 1 351-1 356.
[44] Toyoda S, Ikeya M, Morikawa J, et al . Enhancement of oxygen vacancies in Quartz by natural external beta and Gamma ray Dose: A possible ESR geochronometer of Ma-Ga range[J]. Geochemical Journal , 1992, 26(3): 111-115.
[45] Usami T, Toyoda S, Bahadur H, et al . Characterization of the E ?? center in Quartz: Role of aluminum hole centers and oxygen vacancies[J]. Physica B : Condensed Matter , 2009, 404(20): 3 819-3 823.
[46] Liu Chunru, Yin Gongming, Gao Lu, et al . ESR dating of pleistocene archaeological localities of the Nihewan Basin, North China-preliminary results[J]. Quaternary Geochronology , 2010, 5(2): 385-390.
[47] Duval M, Guilarte V. ESR dosimetry of optically bleached quartz grains extracted from plio-Quaternary sediment: Evaluating some key aspects of the ESR signals associated to the Ti-Centers[J]. Radiation Measurements , 2015, 78: 28-41.
[48] Dennen W H, Blackburn W H, Quesada A. Aluminum in Quartz as age other mometer[J]. Contributions to Mineralogy and Petrology , 1970, 27(4): 332-342.
[49] Wark D A, Watson E B. Titaniq:A titanium-in-Quartz geothermometer[J]. Contributions to Mineralogy and Petrology , 2006, 152(6): 743-754.
[50] Nuttall R H D, Weil J A. The magnetic properties of the oxygen-hole aluminum centers in crystalline SiO 2 . I.
[AlO 4 ][J]. Canadian Journal of Physics , 1981, 59(11): 1 696-1 708.
[51] Larsen R B, Henderson I, Ihlen P M, et al . Distribution and petrogenetic behaviour of trace elements in granitic pegmatite Quartz from South Norway[J]. Contributions to Mineralogy and Petrology , 2004, 147(5): 615-628.
[52] Jacamon F, Larsen R B. Traceelement evolution of Quartz in the charnockitic kleivan granite, SW-Norway: The Ge/Ti ratio of Quartz as an index of igneous differentiation[J]. Lithos , 2009, 107(3): 281-291.
[53] Chen Xiaodan, Chen Zhenyu, Cheng Yanbo, et al . Distribution and application of trace elements in hydrothermal Quartz: Understanding and prospecting[J]. Geological Review , 2011, 57(5): 707-717.
[陈小丹, 陈振宇, 程彦博, 等. 热液石英中微量元素特征及应用: 认识与进展[J]. 地质论评, 2011, 57(5): 707-717.]
[54] Chen Jianfeng, Zhang Hui. Trace elements in Quartz lattice and their implications for petrogenesis and mineralization[J]. Geological Journal of China Universities , 2011, 17(1): 125-135.
[陈剑锋, 张辉. 石英晶格中微量元素组成对成岩成矿作用的示踪意义[J]. 高校地质学报, 2011, 17(1): 125-135.]
[55] Preusser F, Chithambo M L, Götte T, et al . Quartz as a natural luminescence dosimeter[J]. Earth-Science Reviews , 2009, 97(1): 184-214.
[56] Chen Hongyun. ESR Signal Intensity and Crystallinity of Quartz in Desert Surface Sediments and Eolian Deposits on the Chinese Loess Plateau[D]. Beijing: Graduate University of Chinese Academy of Sciences, 2011.
[陈洪云. 沙漠表土和黄土高原风尘沉积中石英颗粒的ESR信号强度和结晶度指数研究[D].北京:中国科学院研究生院, 2011.]
[57] Li Chang’an, Yu Lizhong. Conceptmodel on the fluvial environmental system: Mountain-river-lake-sea interaction and sensitive responding to global change[J]. Resources and Environment in the Yangtze Basin , 2000, 9(3): 358-363.
[李长安, 俞立中. 山—河—湖—海互动及对全球变化的敏感响应: 以长江为例[J]. 长江流域资源与环境, 2000, 9(3): 358-363.]
[58] Li Chang’an. The relationship among human, water and land: Optimizing function of the embankment in the Yangtze River[J]. Earth Science , 2015, 40(2): 261-267.
[李长安. 基于 “人—水—地和谐” 的长江堤防功能[J]. 地球科学, 2015, 40(2): 261-267.]
[59] Wei Chuanyi, Liu Chunru, Li Chang’an, et al . A study on ESR signal intensity and CI provenance—Tracing of Quartz and its potential application to river system sediments[J]. Earth and Environment , 2017, 45(2): 157-163.
[魏传义, 刘春茹, 李长安, 等. 石英ESR法在河流沉积物源示踪中的探讨及应用[J]. 地球与环境, 2017, 45(2): 157-163.]
[60] Wei Chuanyi, Li Chang’an, Liu Chunru, et al . Nature ESR signals of quartz E ?? center shed new light on river sediments provenance: A case study in southeast margin of the Tibet Plateau[J]. Quaternary International ,2017, 454(10): 38-44.
